background image
AXP221
PMIC Optimized For Multi-Core High-Performance System
PAGE 34
Copyright © 2013 X-Powers Limited. All Rights Reserved.
Datasheet
Revision 1.2
10.2.6. REG13H: 电源输出控制
默认值
:01H
Bit
描述
R/W
默认值
7
ALDO3 开关控制
0: 关闭； 1: 打开
RW
0
6-0
保留，不可更改
RW
0
10.2.7. REG15H:DLDO1 输出电压设置
默认值
:00H
Bit
描述
R/W
默认值
7-5
保留，不可更改
4
DLDO1 输出电压设置 Bit4
0.7-3.3V,100mV/step
RW
0
3
DLDO1 输出电压设置 Bit3
RW
0
2
DLDO1 输出电压设置 Bit2
RW
0
1
DLDO1 输出电压设置 Bit1
RW
0
0
DLDO1 输出电压设置 Bit0
RW
0
10.2.8. REG16H:DLDO2 输出电压设置
默认值
:00H
Bit 描述
R/W
默认
值
7-5
保留，不可更改
4
DLDO2 输出电压设置 Bit4
0.7-3.3V,100mV/step
RW
0
3
DLDO2 输出电压设置 Bit3
RW
0
2
DLDO2 输出电压设置 Bit2
RW
0
1
DLDO2 输出电压设置 Bit1
RW
0
0
DLDO2 输出电压设置 Bit0
RW
0
10.2.9. REG17H:DLDO3 输出电压设置
默认值
:00H
Bit
描述
R/W
默认值
7-5
保留，不可更改
4
DLDO3 输出电压设置 Bit4
0.7-3.3V,100mV/step
RW
0
3
DLDO3 输出电压设置 Bit3
RW
0
2
DLDO3 输出电压设置 Bit2
RW
0
1
DLDO3 输出电压设置 Bit1
RW
0
0
DLDO3 输出电压设置 Bit0
RW
0
