AXP221
PMIC Optimized For Multi-Core High-Performance System
PAGE 38
Copyright © 2013 X-Powers Limited. All Rights Reserved.
Datasheet
Revision 1.2
Bit
描述
R/W
默认值
1
DC-DC3 VRC 电压上升斜率控制
0: 20mV/15.625us=1.6mV/us
1: 20mV/31.250us=0.8mV/us
RW
0
0
DC-DC2 VRC 电压上升斜率控制
0: 20mV/15.625us=1.6mV/us
1: 20mV/31.250us=0.8mV/us
RW
0
10.2.21.REG28H:ALDO1 输出电压设置
默认值
:00H
Bit
描述
R/W
默认值
7-5
保留，不可更改
4
ALDO1 输出电压设置 Bit4
0.7-3.3V,100mV/step
RW
0
3
ALDO1 输出电压设置 Bit3
RW
0
2
ALDO1 输出电压设置 Bit2
RW
0
1
ALDO1 输出电压设置 Bit1
RW
0
0
ALDO1 输出电压设置 Bit0
RW
0
10.2.22.REG29H:ALDO2 输出电压设置
默认值
:00H
Bit
描述
R/W
默认值
7-5
保留，不可更改
4
ALDO2 输出电压设置 Bit4
0.7-3.3V,100mV/step
RW
0
3
ALDO2 输出电压设置 Bit3
RW
1
2
ALDO2 输出电压设置 Bit2
RW
0
1
ALDO2 输出电压设置 Bit1
RW
1
0
ALDO2 输出电压设置 Bit0
RW
1
10.2.23.REG2AH:ALDO3 输出电压设置
默认值
:00H
Bit
描述
R/W
默认值
7-5
保留，不可更改
4
ALDO3 输出电压设置 Bit4
0.7-3.3V,100mV/step
RW
1
3
ALDO3 输出电压设置 Bit3
RW
0
2
ALDO3 输出电压设置 Bit2
RW
1
1
ALDO3 输出电压设置 Bit1
RW
1
0
ALDO3 输出电压设置 Bit0
RW
1
