QPD1025L

1500 W, 65 V, 1.0

– 1.1 GHz, GaN RF Input-Matched Transistor

Datasheet Rev. B

│ Subject to change without notice

- 18 of 18 -

www.qorvo.com

Handling Precautions

Parameter

Rating

Standard

Caution!

ESD-Sensitive Device

ESD – Human Body Model (HBM)

Class 1C

JEDEC JS-001

ESD – Charged Device Model (CDM)

Class C3

JEDEC JS-002

MSL – Moisture Sensitivity Level

MSL3

JESD J-STD-020

(260°C Convection reflow)

Contact Information

For the latest specifications, additional product information, worldwide sales and distribution locations, and information about

Qorvo:

Web:

www.Qorvo.com

Tel:

+1.972.994.8465

Email: info-sales@qorvo.com

Fax:

+1.972.994.8504

For technical questions and application information:

Email: info-products@qorvo.com

Important Notice

The information contained herein is believed to be reliable; however, Qorvo makes no warranties regarding the information contained

herein and assumes no responsibility or liability whatsoever for the use of the information contained herein. All information contained

herein is subject to change without notice. Customers should obtain and verify the latest relevant information before placing orders for

Qorvo products. The information contained herein or any use of such information does not grant, explicitly or implicitly, to any party any

patent rights, licenses, or any other intellectual property rights, whether with regard to such information itself or anything described by

such information. THIS INFORMATION DOES NOT CONSTITUTE A WARRANTY WITH RESPECT TO THE PRODUCTS DESCRIBED

HEREIN, AND QORVO HEREBY DISCLAIMS ANY AND ALL WARRANTIES WITH RESPECT TO SUCH PRODUCTS WHETHER

EXPRESS OR IMPLIED BY LAW, COURSE OF DEALING, COURSE OF PERFORMANCE, USAGE OF TRADE OR OTHERWISE,

INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Without limiting the generality of the foregoing, Qorvo products are not warranted or authorized for use as critical components in medical,

life-saving, or life-sustaining applications, or other applications where a failure would reasonably be expected to cause severe personal

injury or death.

Copyright 2017 © Qorvo, Inc. | Qorvo is a registered trademark of Qorvo, Inc.

Solderability

Compatible with both lead-free (260°C max. reflow temp.) and tin/lead (245°C max. reflow temp.) soldering processes.

Solder profiles available upon request.

Contact plating: NiAu

RoHS Compliance

This part is compliant with 2011/65/EU RoHS directive (Restrictions on the Use of Certain Hazardous Substances in Electrical and

Electronic Equipment) as amended by Directive 2015/863/EU.

This product also has the following attributes:

• Halogen Free (Chlorine, Bromine)

• Antimony Free

• SVHC Free

Pb
