MB90347CEPMC Datasheet(PDF) 32 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB90347CEPMC Datasheet(HTML) 32 Page - Cypress Semiconductor |
|
|
32 / 93 page  Document Number: 002-04498 Rev. *A Page 31 of 92 MB90340E Series (Continued) Address Register Abbreviation Access Resource name Initial value 000020H Serial Mode Register 0 SMR0 W,R/W UART0 00000000B 000021H Serial Control Register 0 SCR0 W,R/W 00000000B 000022H Reception/Transmission Data Register 0 RDR0/TDR0 R/W 00000000B 000023H Serial Status Register 0 SSR0 R,R/W 00001000B 000024H Extended Communication Control Register 0 ECCR0 R,W, R/W 000000XXB 000025H Extended Status/Control Register 0 ESCR0 R/W 00000100B 000026H Baud Rate Generator Register 00 BGR00 R/W 00000000B 000027H Baud Rate Generator Register 01 BGR01 R/W 00000000B 000028H Serial Mode Register 1 SMR1 W,R/W UART1 00000000B 000029H Serial Control Register 1 SCR1 W,R/W 00000000B 00002AH Reception/Transmission Data Register 1 RDR1/TDR1 R/W 00000000B 00002BH Serial Status Register 1 SSR1 R,R/W 00001000B 00002CH Extended Communication Control Register 1 ECCR1 R,W, R/W 000000XXB 00002DH Extended Status/Control Register 1 ESCR1 R/W 00000100B 00002EH Baud Rate Generator Register 10 BGR10 R/W 00000000B 00002FH Baud Rate Generator Register 11 BGR11 R/W 00000000B 000030H PPG 0 Operation Mode Control Register PPGC0 W,R/W 16-bit PPG 0/1 0X000XX1B 000031H PPG 1 Operation Mode Control Register PPGC1 W,R/W 0X000001B 000032H PPG 0/PPG 1 Count Clock Select Register PPG01 R/W 000000X0B 000033H Reserved 000034H PPG 2 Operation Mode Control Register PPGC2 W,R/W 16-bit PPG 2/3 0X000XX1B 000035H PPG 3 Operation Mode Control Register PPGC3 W,R/W 0X000001B 000036H PPG 2/PPG 3 Count Clock Select Register PPG23 R/W 000000X0B 000037H Reserved 000038H PPG 4 Operation Mode Control Register PPGC4 W,R/W 16-bit PPG 4/5 0X000XX1B 000039H PPG 5 Operation Mode Control Register PPGC5 W,R/W 0X000001B 00003AH PPG 4/PPG 5 Clock Select Register PPG45 R/W 000000X0B 00003BH Address Detect Control Register 1 PACSR1 R/W Address Match Detection 1 00000000B 00003CH PPG 6 Operation Mode Control Register PPGC6 W,R/W 16-bit PPG 6/7 0X000XX1B 00003DH PPG 7 Operation Mode Control Register PPGC7 W,R/W 0X000001B 00003EH PPG 6/PPG 7 Count Clock Control Register PPG67 R/W 000000X0B 00003FH Reserved |
|
