STM32U545NET3QTR Datasheet(PDF) 210 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
STM32U545NET3QTR Datasheet(HTML) 210 Page - STMicroelectronics |
|
|
210 / 283 page  Electrical characteristics STM32U545xx 210/283 DS14216 Rev 1 Output AC characteristics The definition and values of output AC characteristics are given in Figure 35: Output AC characteristics definition and in the table below respectively. Unless otherwise specified, the parameters given are derived from tests performed under the ambient temperature and supply voltage conditions summarized in Table 33. Table 96. Output AC characteristics, HSLV OFF (all I/Os except FT_c, FT_t in VBAT mode, and FT_o I/Os(1))(2)(3)(4) Speed Symbol Parameter Conditions Min Max Unit 00 Fmax Maximum frequency all I/Os CL = 50 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 12.5 MHz CL = 50 pF, 1.58 V ≤ VDDIOx < 2.7 V - 5 CL = 50 pF, 1.08 V ≤ VDDIOx < 1.58 V - 1 CL = 10 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 12.5 CL = 10 pF, 1.58 V ≤ VDDIOx < 2.7 V - 5 CL = 10 pF, 1.08 V ≤ VDDIOx < 1.58 V - 1 tr/tf Output rise and fall time all I/Os CL = 50 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 17 ns CL = 50 pF, 1.58 V ≤ VDDIOx < 2.7 V - 33 CL = 50 pF, 1.08 V ≤ VDDIOx < 1.58 V - 85 CL = 10 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 12.5 CL = 10 pF, 1.58 V ≤ VDDIOx < 2.7 V - 25 CL = 10 pF, 1.08 V ≤ VDDIOx < 1.58 V - 50 01 Fmax Maximum frequency all I/Os CL = 30 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 55 MHz CL = 30 pF, 1.58 V ≤ VDDIOx < 2.7 V - 12.5 CL = 30 pF, 1.08 V ≤ VDDIOx < 1.58 V - 2.5 CL = 10 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 55 CL = 10 pF, 1.58 V ≤ VDDIOx < 2.7 V - 12.5 CL = 10 pF, 1.08 V ≤ VDDIOx ≤<1.58 V - 2.5 tr/tf Output rise and fall time all I/Os CL = 30 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 5.8 ns CL = 30 pF, 1.58 V ≤ VDDIOx < 2.7 V - 10 CL = 30 pF, 1.08 V ≤ VDDIOx < 1.58 V - 18 CL = 10 pF, 2.7 V ≤ VDDIOx ≤ 3.6 V - 4.2 CL = 10 pF, 1.58 V ≤ VDDIOx < 2.7 V - 7.5 CL = 10 pF, 1.08 V ≤ VDDIOx < 1.58 V - 12 |
|
