DocID030181 Rev 2

31/99

AN4989

Connecting to the board

Especially since JTAG is using more pins, users should be aware that it is at the expense of

using some IPs.

Refer to the product datasheet for a detailed presentation of the default and alternative

function mapping for each pin.

4.2

Reset and connection mode

This section reviews the reset and connection mode available while using ST-LINK/V2

debug interface.

4.2.1

Presentation

Connection mode and reset mode are 2 different but dependent concepts:

Reset mode can be either:

•

Hardware: drive the NRST pin of the MCU. In all STMicroelectronics hardware kits, the

debugger can drive this NRST through ST-LINK/V2.

Hint:

On Nucleo, check that relevant Solder Bridge SB12 is not OFF.

•

Software (write to core register)

–

System: Core and all Peripheral SOC IPs are reset

–

Core: Only ARM® Cortex® is reset

Connection mode can be either:

•

Normal: Debugger takes control through JTAG/SWD port and starts execution after a

software reset.

This is working only if JTAG/SWD is available:

–

GPIO correctly configured and clocked

–

FCLK or HCLK enabled

–

Main Power domain or Low-Power debug active

•

ConnectUnderReset: Debugger takes control while asserted NRST pin, setting GPIO

and clock into there default state.

This is required in case of a reconnection to a system in Low-Power mode or which has

changed SWD pin to alternate functions.

•

Hotplug: Debugger connect without reset nor halt. Once connected, the user can chose

to perform the required action (typically halt to get where the program stands and read

registers or memory for instance).

Reset and Connection mode are differently accessible and exposed depending on tool and

IDE.
