ADP5360

Data Sheet

Rev. 0 | Page 4 of 60

SPECIFICATIONS

BATTERY CHARGER SPECIFICATIONS

TJ = −40°C to +85°C, voltage of the VBUS pin (VVBUS) = 5.0 V, voltage of the ISOB pin (VISOB) = 3.8 V, C1 = 2.2 μF, C2 = 1 μF, C3 = C4 =

10 μF (see Figure 60), and all registers are at default values, unless otherwise noted.

Table 1.

Parameter

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

GENERAL PARAMETERS

Undervoltage Lockout (UVLO)

VUVLO

Rising threshold, voltage of the ISOB pin,

VVBUS = 0 V

2.1

2.15

Falling threshold, voltage of the ISOB pin,

VVBUS = 0 V

1.8

1.88

Input Current Limit

ILIM

ILIM = 100 mA

100

Operation Current

VBUS Consumption

IQ_BUS

Charger, fuel gauge, buck, and buck boost

enabled, no charge current

1.5

Battery Consumption

IQ_PRO

Enable battery protection only, VVBUS = 0 V

0.25

1.8

μA

IQ_FG_ACT

Fuel gauge, active mode, VVBUS = 0 V

3.5

μA

IQ_FG_SLEEP

Fuel gauge, sleep mode, VVBUS = 0 V

0.2

0.85

μA

IQ_REG

Enable buck and buck boost, VVBUS = 0 V

0.34

μA

IQ_DISALL

All disabled, VVBUS = 0 V

150

450

IQ_SHIP

Shipment mode, TJ = 25°C

Shipment mode, TJ = −40°C to +85°C

310

CHARGING PARAMETERS

Fast Charge Constant Current

Mode

ICHG

ICHG = 100 mA

100

106

Accuracy1

ICHG = 10 mA to 320 mA, TJ = 0°C to 85°C

−15

+15

Charge Current

Trickle1

ITRK_DEAD

ITRK_DEAD = 5 mA, TJ = 0°C to 85°C

Weak

ICHG_WEAK

ITRK_DEAD + ICHG

Trickle to Weak Charge Threshold1

VTRK_DEAD

VTRK_DEAD = 2.5 V

2.41

2.5

2.57

Hysteresis

ΔVTRK_DEAD

100

Weak to Fast Charge Threshold1

VWEAK

VWEAK = 3.0 V

2.88

3.0

3.08

Hysteresis

ΔVWEAK

100

Battery Termination Voltage

VTRM

Termination Voltage Accuracy1

VTRM = 4.2 V on the BSNS pin, TJ = 25°C

4.18

4.200

4.22

VTRM = 4.2 V, on the BSNS pin, TJ = 0°C to 85°C

−1

Charge Complete Current1

IEND

IEND = 5 mA, TJ = 0°C to 85°C

Recharge Voltage Differential1

VRCH

120

BATTERY ISOLATION FET

ISOFET

Resistance Between ISOB and VSYS

RDSON_ISO

VVBUS = 0 V, current of the ISOB pin (IISOB) =

100 mA

145

220

mΩ

LOW DROPOUT (LDO) AND HIGH VOLTAGE

BLOCKING FET

Regulated System Voltage1

VSYS_REG

VTRM = 4.2 V, VSYSTEM = VTRM + 200 mV

4.4

High Voltage Blocking FET On Resistance

RDSON_HV

IVBUS = 100 mA

550

820

mΩ

Input Operating Voltage Range

VVBUS

4.1

6.8

Good Threshold

VVBUS_OK

Rising

VVBUS_OK_RISE

3.9

4.0

Falling

VVBUS_OK_FALL

3.5

3.6

Overvoltage Threshold

VVBUS_OV

Rising

VVBUS_OV_RISE

6.8

7.0

Falling

VVBUS_OV_FALL

6.4

6.6
