Data Sheet

ADP5360

Rev. 0 | Page 47 of 60

Table 52. BAT_SOCACM_CTL, Address 0x22 Bit Descriptions

Bit(s)

Bit Name

Access Default

Description

[7:6]

BATCAP_AGE[1:0]

R/W

01 = 1.5%

Battery Capacity Reduction Percentage When BAT_SOCACM Overflows.

00 = 0.8 %.

01 = 1.5 %.

10 = 3.1 %.

11 = 6.3 %.

[5:4]

BATCAP_TEMP[1:0]

R/W

00 = 0.2%/°C

Battery Capacity Compensation with Temperature Coefficient. The values of the

battery capacity compensation can be programmed by using the following values:

00 = 0.2 %/°C.

01 = 0.4 %/°C.

10 = 0.6 %/°C.

11 = 0.8 %/°C.

[3:2]

Reserved

Not applicable

Reserved

EN_BATCAP_TEMP

R/W

Battery Capacity Temperature Compensation Function Selection.

0 = disable battery capacity temperature compensation.

1 = enable battery capacity temperature compensation.

EN_BATCAP_AGE

R/W

Battery Capacity Aging Compensation Function Selection.

0 = disable battery capacity aging automatic adjustment.

1 = enable battery capacity aging automatic adjustment.

Table 53. BAT_SOCACM_H, Address 0x23 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

BAT_SOCACM[11:4]

Not applicable

Highest Eight Bits of an 8-Bit Accumulation of the Charge State

Number of Times for Charging = BAT_SOCACM[11:0]/100

Table 54. BAT_SOCACM_L, Address 0x24 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:4]

BAT_SOCACM[3:0]

Not applicable

Lowest Four Bits of a 4-Bit Accumulation of the Charge State

Number of Times for Charging = BAT_SOCACM[11:0]/100

[3:0]

Reserved

Not applicable

Reserved

Table 55. VBAT_READ_H, Address 0x25 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

VBAT_READ[12:5]

Not applicable

Battery Voltage Reading of the Highest Eight Bits (mV)

Table 56. VBAT_READ_L, Address 0x26 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:3]

VBAT_READ[4:0]

Not applicable

Battery Voltage Reading of the Lowest Five Bits (mV)

[2:0]

Reserved

Not applicable

Reserved

Table 57. FUEL_GAUGE_MODE, Address 0x27 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:6]

SOC_LOW_TH[1:0]

R/W

01 = 11%

Indication of Low State of Charge Threshold

00 = 6%

01 = 11%

10 = 21%

11 = 31%

[5:4]

SLP_CURR[1:0]

R/W

01 = 10 mA

Fuel Gauge Sleep Mode Current Threshold

00 = 5 mA

01 = 10 mA

10 = 20 mA

11 = 40 mA
