ADP5360

Data Sheet

Rev. 0 | Page 46 of 60

Table 42. V_SOC_11, Address 0x18 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_11[7:0]

R/W

0x94

Battery Voltage When State of Charge = 11%. The default voltage is 3.684 V.

Battery voltage (V) = (2.5 + V_SOC_11 × 0.008) (V).

Table 43. V_SOC_19, Address 0x19 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_19[7:0]

R/W

0x99

Battery Voltage When State of Charge = 19%. The default voltage is 3.724 V.

Battery voltage (V) = (2.5 + V_SOC_19 × 0.008) (V).

Table 44. V_SOC_28, Address 0x1A Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_28[7:0]

R/W

0x9E

Battery Voltage When State of Charge = 28%. The default voltage is 3.764 V.

Battery Voltage (V) = (2.5 + V_SOC_28 × 0.008) (V).

Table 45. V_SOC_41, Address 0x1B Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_41[7:0]

R/W

0xA3

Battery Voltage When State of Charge = 41%. The default voltage is 3.804 V.

Battery Voltage (V) = (2.5 + V_SOC_41 × 0.008) (V).

Table 46. V_SOC_55, Address 0x1C Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_55[7:0]

R/W

0xAB

Battery Voltage When State of Charge = 55%. The default voltage is 3.868 V.

Battery Voltage (V) = (2.5 + V_SOC_55 × 0.008) (V).

Table 47. V_SOC_69, Address 0x1D Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_69[7:0]

R/W

0xB5

Battery Voltage When State of Charge = 69%. The default voltage is 3.948 V.

Battery Voltage (V) = (2.5 + V_SOC_69 × 0.008) (V).

Table 48. V_SOC_84, Address 0x1E Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_84[7:0]

R/W

0xC4

Battery Voltage When State of Charge = 84%. The default voltage is 4.068 V.

Battery Voltage (V) = (2.5 + V_SOC_84 × 0.008) (V).

Table 49. V_SOC_100, Address 0x1F Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

V_SOC_100[7:0]

R/W

0xD5

Battery Voltage When State of Charge = 100%. The default voltage is 4.204 V.

Battery Voltage (V) = (2.5 + V_SOC_100 × 0.008) (V).

Table 50. BAT_CAP, Address 0x20 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

[7:0]

BAT_CAP[7:0]

R/W

0x32

Battery Capacity Input

Battery Capacity = (BAT_CAP × 2) mAh

Table 51. BAT_SOC, Address 0x21 Bit Descriptions

Bit(s)

Bit Name

Access

Default

Description

Reserved

Not applicable

Reserved

[6:0]

BAT_SOC[6:0]

Not applicable

Battery State of Charge Output

State of Charge = BAT_SOC %, Only Valued Between 0% to 100%
