ADP5360

Data Sheet

Rev. 0 | Page 18 of 60

CH1 1.00V

CH2 2.00V

M4.00ms

A CH1

600mV

T 9.960000ms

CH3 5.00V

CH4 200mA

VOUT1

VSW1

VPGOOD1

IL1

Figure 38. Buck Output Soft Start, Set EN_BUCK High,

PWM Mode, VVIN1 = 3.8 V, VOUT1 = 1.2 V, PGOOD1 Mask to Buck Output

(VOUT1), IOUT1 = 1 mA, tSS1 = 8 ms

CH1 1.00V

CH2 5.00V

M40.0ms

A CH4

2.50V

CH3 5.00V

CH4 5.00V BW

VOUT1

VSW1

VPGOOD1

VSTP

Figure 39. Buck Stop Function Waveform, VVIN1 = 3.8 V, VOUT1 = 1.2 V,

Hysteresis Mode, PGOOD1 Mask to VOUT1, STP_BUCK = 1 Bit

CH1 50.0mV

M100µs A CH4

82.0mA

T 289.0000µs

CH4 100mA BW

VOUT1

IOUT1

Figure 40. Buck Output Transient Waveform, VVIN1 = 3.8 V, VOUT1 = 1.2 V,

IOUT1 = 1 mA to 100 mA, PWM Mode

CH1 50.0mV

M4.00ms

A CH4

62.0mA

T 11.96920ms

CH4 100mA BW

VOUT1

IOUT1

Figure 41. Buck Output Transient Waveform, VVIN1 = 3.8 V, VOUT1 = 1.2 V,

IOUT1 = 1 mA to 100 mA, Hysteresis Mode

CH1 5.00V

CH2 5.00V

M4.00ms

A CH1

3.40V

T 11.08000ms

CH3 5.00V

CH4 200mA BW

VPGOOD2

VSW2A

VSW2B

VVOUT2

Figure 42. Buck Boost Output SoftStart Waveform, VVIN2 = 3.8 V, VOUT2 =5 V,

BUCKBST_SS[0:1] = 8 ms, Buck Boost Output Current (IOUT2) = 1 mA,

PGOOD2 Mask to VOUT2

CH1 100mV

CH2 5.00V

M200µs

A CH2

2.70V

T 0.000000s

CH3 5.00V

CH4 100mA BW

VVOUT2

VSW2B

VSW2A

IL2

Figure 43. Buck Boost Steady Waveform, VVIN2 = 3.8 V,

VOUT2 = 5 V, IOUT2 = 1 mA
