72 / 121 page

D a t a S h e e t

December 16, 2014, MB9A110A-DS706-00011-3v0-E

CONFIDENTIAL

 Pin Characteristics

(Vcc = AVcc = 2.7V to 5.5V, Vss = AVss = 0V, Ta = - 40°C to + 105°C)

Parameter

Symbol Pin name

Conditions

Value

Unit Remarks

Min

Typ

Max

"H" level

input

voltage

(hysteresis

input)

VIHS

CMOS

hysteresis

input pin,

MD0,1

Vcc × 0.8

Vcc + 0.3

5V tolerant

I/O pin

Vcc × 0.8

Vss + 5.5

"L" level input

voltage

(hysteresis

input)

VILS

CMOS

hysteresis

input pin,

MD0,1

Vss - 0.3

Vcc × 0.2

"H" level

output voltage

VOH

4mA type

Vcc ≥ 4.5 V

IOH = - 4mA

Vcc - 0.5

Vcc

Vcc < 4.5 V

IOH = - 2mA

12mA type

Vcc ≥ 4.5 V

IOH = - 12mA

Vcc - 0.5

Vcc

Vcc < 4.5 V

IOH = - 8mA

P80, P81

Vcc ≥ 4.5 V

IOH = - 20.5mA

Vcc - 0.4

Vcc

Vcc < 4.5 V

IOH = - 13.0mA

"L" level

output voltage

VOL

4mA type

Vcc ≥ 4.5 V

IOL = 4mA

Vss

0.4

Vcc < 4.5 V

IOL = 2mA

12mA type

Vcc ≥ 4.5 V

IOL = 12mA

Vss

0.4

Vcc < 4.5 V

IOL = 8mA

P80, P81

Vcc ≥ 4.5 V

IOL = 18.5mA

Vss

0.4

Vcc < 4.5 V

IOL = 10.5mA

Input leak

current

IIL

- 5

+ 5

μA

Pull-up

resistor

value

RPU

Pull-up pin

Vcc ≥ 4.5 V

100

kΩ

Vcc < 4.5 V

200

Input

capacitance

CIN

Other than

Vcc, Vss,

AVcc, AVss,

AVRH
