Serial Interface with Time-Slot Assigner

MPC8280 PowerQUICC II Family Reference Manual, Rev. 1

Freescale Semiconductor

15-29

MPC8280 then stops sending and retransmits the frame when L1GRx is reasserted. This procedure is

handled automatically for the first two buffers of a frame.

For the primary rate IDL, the MPC8280 supports up to four 8-bit channels in the frame, determined by the

SIx RAM programming. To support more channels, the user can route more than one channel to each SCC

and the SCC treats it as one high-speed stream and store it in the same data buffers (appropriate only for

transparent data). Additionally, the MPC8280 can be used to assert strobes for support of additional

external IDL channels.

The IDL interface supports the CCITT I.460 recommendation for data-rate adaptation since it separately

accesses each bit of the IDL bus. The current-route RAM specifies which bits are supported by the IDL

interface and by which serial controller. The receiver only receives bits that are enabled by the receiver

route RAM. Otherwise, the transmitter sends only bits that are enabled by the transmitter route RAM and

three-states L1TXDx.

15.6.2

IDL Interface Programming

To program an IDL interface, first program SIxMR[GMx] to the IDL grant mode for that channel. If the

receive and transmit sections interface to the same IDL bus, set SIxMR[CRTx] to internally connect the

Rx clock and sync signals to the transmit section. Then, program the SIx RAM used for the IDL channels

to the preferred routing. See Section 15.4.4, “SIx RAM Programming Example.”

Define the IDL frame structure by programming SIxMR[xFSDx] to have a 1-bit delay from frame sync to

data, SIxMR[FEx] to sample on the falling edge, and SIxMR[CEx] to transmit on the rising edge of the

clock. Program the parallel I/O open-drain register so that L1TXDx is three-stated when inactive; see

Section 41.2.1, “Port Open-Drain Registers (PODRA–PODRD).” To support the D channel, program the

appropriate CMXSCR[GRx] bit, as described in Section 16.4.5, “CMX SCC Clock Route Register

(CMXSCR),” and program the SIx RAM entry to route data to the chosen serial controller. The two

definitions of IDL, 8 or 10 bits, are implemented by simply modifying the SIx RAM programming. In both

cases, L1GRx is sampled while L1TSYNCx is asserted and transferred to the D-channel SCC as a grant

indication.

For example, based on the same 10-bit format as in Section 15.4.4, “SIx RAM Programming Example,”

implement an IDL bus using SCC1, SCC2, and SMC1 connected to TDMa1 as follows:

1. Program both the Tx and Rx sections of the SIx RAM as in Table 15-10.

Table 15-10. SI

x RAM Entries for an IDL Interface

Entry

Number

x RAM Entry

MCC

SWTR

SSEL

CSEL

CNT

BYT

LST

Description

0000

0010

000

8-bit SCC2

0000

0001

000

1-bit SCC1

0000

000

1-bit no

support

0000

0101

011

4-bit SMC1
