PACKAGE MATERIALS INFORMATION
www.ti.com
15-Jul-2025
TAPE AND REEL BOX DIMENSIONS
Width (mm)
H
*All dimensions are nominal
Device
Package Type
Package Drawing
Pins
SPQ
Length (mm)
Width (mm)
Height (mm)
DRV8876PWPR
HTSSOP
PWP
16
2000
350.0
350.0
43.0
DRV8876PWPRG4
HTSSOP
PWP
16
2000
350.0
350.0
43.0
DRV8876RGTR
VQFN
RGT
16
3000
367.0
367.0
35.0
Pack Materials-Page 2
