Preliminary
TTP259
TonTouch
TM
2015/05/25
Page 76 of 81
Ver: 1.1
§ Mask Option Table:
All the OTP mask option register can open for user to reset the initial value,
but should enable the MRO. User writes MRO address first then changes the
target mask option register data. The MRO enable will be cleared with other
writing address. Bit 3 of MOP0 must always set to 1.
MOP0: LVR voltage select option register [R/W], default value [1-0-]
Mask option
Bit3
Bit2
Bit1
Bit0
Bit Name
1
-
LVRVS
-
Read/Write
R/W
-
R/W
-
MOP1: PWM start level option register [R/W], default value [-000]
Mask option
Bit3
Bit2
Bit1
Bit0
Bit Name
-
PWM2S
PWM1S
PWM0S
Read/Write
-
R/W
R/W
R/W
MOP2: INT trigger option register [R/W], default value [0000]
Mask option
Bit3
Bit2
Bit1
Bit0
Bit Name
INT1S1
INT1S0
INT0S1
INT0S0
Read/Write
R/W
R/W
R/W
R/W
MOP3: Function pin select 1st option register [R/W], default value [0000]
Mask option
Bit3
Bit2
Bit1
Bit0
Bit Name
PWM1PS
PWM0PS
INT1PS
INT0PS
Read/Write
R/W
R/W
R/W
R/W
MOP4: Function select option register [R/W], default value [0--0]
Mask option
Bit3
Bit2
Bit1
Bit0
Bit Name
LVREN
-
-
LDOVS
Read/Write
R/W
-
-
R/W
MOP5: Function pin select 2nd option register [R/W], default value [000-]
Mask option
Bit3
Bit2
Bit1
Bit0
Bit Name
PWM2PS1
PWM2PS0
SpecIO
-
Read/Write
R/W
R/W
R/W
-
