TTP259-ASFN Datasheet(PDF) 13 Page - Tontek Design Technology |
|
|
|||||||||||||||||||||||||||||
TTP259-ASFN Datasheet(HTML) 13 Page - Tontek Design Technology |
|
|
13 / 81 page  Preliminary TTP259 TonTouch TM 2015/05/25 Page 13 of 81 Ver: 1.1 200H TCP1C R/W 0000 TCP1 Timer/counter control register 201H TCP1L R/W xxxx TCP1 Timer/counter data low register 202H TCP1H R/W xxxx TCP1 Timer/counter data high register 203H TCP2C R/W 0000 TCP2 Timer/counter control register 204H TCP2L R/W xxxx TCP2 Timer/counter data low register 205H TCP2M R/W xxxx TCP2 Timer/counter data middle register 206H TCP2H R/W xxxx TCP2 Timer/counter data high register 207H PAI R ---- Port A pad data reading address 208H PBI R ---- Port B pad data reading address 209H PCI R ---- Port C pad data reading address 20AH PDI R ---- Port D pad data reading address 20BH PEI R ---- Port E pad data reading address 20CH PFI R ---- Port F pad data reading address 20DH TCPFS R/W -000 TCP clock source FS pre-scale register 20EH TBC R/W 1111 Time base control register 20FH - - ---- - 210H TPCHS0 R/W 0000 Touch pad channel selector register 0 211H TPCHS1 R/W 0000 Touch pad channel selector register 1 212H TPCHS2 R/W 0000 Touch pad channel selector register 2 213H TPCHS3 R/W 0000 Touch pad channel selector register 3 214H TPCTL R/W -000 Touch pad control register 215H TPCT0 R/W 1111 Touch pad Duty counter 1st nibble 216H TPCT1 R/W 1111 Touch pad Duty counter 2nd nibble 217H TPCT2 R/W 1111 Touch pad Duty counter 3rd nibble 218H CSAL R/W 0000 Touch pad C load low nibble 219H CSAH R/W --00 Touch pad C load high nibble 21AH MCKS R/W -111 Modulation clock selector register 21BH SPCON0 R/W 0000 Special control register 0 21CH SPCON1 R/W 0000 Special control register 1 21DH SPCON2 R/W --00 Special control register 2 21EH LDOFLAG R/W ---0 LDO fail flag 21FH ODATA R/W 0000 Touch pad output register for special function 220H OSCHADJ R/W 0001 OSCH frequency adjustment register |
|
