Preliminary

TTP259

TonTouch

2015/05/25

Page 42 of 81

Ver: 1.1

Set IICCON1<0> (IICEN) can enable all IIC block, IICCON0<0> (IICMOD)

can select IIC operation in normal mode or fast read mode. The first byte of

data transfer immediately following the START signal is the slave address

transmitted by the master. This is a seven bit long calling address followed by

a R/W bit in Normal mode. Fast read mode only have transmit mode, so R/W

bit must be 1.

When START signal is detected, IICSTS<2> (MBB) is set. When STOP

signal is detected, MBB is cleared. IICSTS<3> (MAASF) is set, when IIC

device match the calling address. When MAASF is set, and INTF1<2> (IICF)

is also set. An interrupt is generated if the INTC1<2> (IICIE) be set. User can

check IICSTS<1> (SRWB) to know IIC device operate in transmit or receive

mode. When IICF is set, an interrupt is generated to the CPU. IICF is set when

one of the following event occurs:

1) IIC device address match in normal mode.

2) Completion of one byte of data transfer. It is set at the falling edge of

the 9th clock in normal mode.

3) Completion of IICRDAT(L/H)0 data transfer and IICRDAT(L/H)1 load

on IICDAT(L/H) in fast read mode.

When IIC device operate in transmit mode, master’s acknowledge store in

IICSTS<0> (TXACK). If detect acknowledge, this bit set, if not, this bit clear.

IICDAT(L/H) only use in normal mode. In transmit mode, data written into

the register to send to the bus automatically, with the most significant bit out

first. In receive mode, reading of this register initiates receiving of the next

byte data. IICRDAT(L/H)0 and IICRDAT(L/H)1 only use in fast mode. IIC

device transmit IICRDAT(L/H)0 first, completion of transfer, IICRDAT(L/H)1

continue transmit to bus automatically.

Whenever IICRDAT(L/H)0 transfer is complete, IICRDAT(L/H)1 will

automatically load transfer buffer, and generates an interrupt flag notify

updatable. If the data transfer will be more than two bytes, you can create a

data counter, interrupt flag is generated every time, data will be placed in

IICRDAT(L/H)0 and IICRDAT(L/H)1 by order by software, however, if the

master halfway want to re-read the beginning of the data, when the data

counter is not starting from scratch, data can not be read correctly, this

situation can be set STIE be 1, when receiving the START signal from IIC BUS,

an interrupt is generated, by receiving this start signal, the data counter is reset

by the software, so you can re-read the data correctly. STIF can only be actived

in fast read mode.
