25 / 81 page  Preliminary TTP259 TonTouch TM 2015/05/25 Page 25 of 81 Ver: 1.1 INTC[00AH]: Interrupt control register [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name TB2IE TCP2IE TCP1IE TB1IE Read/Write R/W R/W R/W R/W TB1IE: Enable time base 1st interrupt. (0: disable; 1: enable) TCP1IE: Enable interrupt of TCP1 timer/counter. (0: disable; 1: enable) TCP2IE: Enable interrupt of TCP2 timer/counter. (0: disable; 1: enable) TB2IE: Enable time base 2nd interrupt. (0: disable; 1: enable) INTF[00BH]: Interrupt request flag register [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name TB2F TCP2F TCP1F TB1F Read/Write R/W R/W R/W R/W TB1F: Time base 1st interrupt request flag. (0: inactive; 1: active) TCP1F: TCP1 Timer/counter interrupt request flag. (0: inactive; 1: active) TCP2F: TCP2 Timer/counter interrupt request flag. (0: inactive; 1: active) TB2F: Time base 2nd interrupt request flag. (0: inactive; 1: active) INTC1[00CH]: Extended interrupt control register [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name STIE IICIE INT1IE INT0IE Read/Write R/W R/W R/W R/W INT0IE: Enable INT0 external interrupt. (0: disable; 1: enable) INT1IE: Enable INT1 external interrupt. (0: disable; 1: enable) IICIE: Enable IIC interrupt. (0: disable; 1: enable) STIE: Enable IIC start signal interrupt. (0: disable; 1: enable) INTF1[00DH]: Extended interrupt request flag register [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name STIF IICF INT1F INT0F Read/Write R/W R/W R/W R/W INT0F: INT0 external interrupt request flag. (0: inactive; 1: active) INT1F: INT1 external interrupt request flag. (0: inactive; 1: active) IICF: IIC interrupt request flag. (0: inactive; 1: active) STIF: IIC start signal interrupt request flag. (0: inactive; 1: active) |
|
