background image
Preliminary
TTP259
TonTouch
TM
2015/05/25
Page 11 of 81
Ver: 1.1
§ Memory Map:
ROM ADDRESS
RAM ADDRESS
Function Block
000H~FBFH
-
Program ROM [4032*16]
-
000H~007H
File Registers
-
008H~01FH
Peripheral registers (I)
-
020H~19FH
Working RAM [384*4]
-
200H~304H
Peripheral registers (II)
§ Interrupt Vectors:
Interrupt Vectors
Function Description
$000
Hardware reset
$001
Hardware interrupt
§ File registers:
Address Symbol R/W Default
Description
000H
(DP1)
R/W
----
Indirect addressing register
001H
ACC
R/W
xxxx
Accumulator and read table 1st data
002H
TB1
R/W
xxxx
Read table 2nd data
003H
TB2
R/W
xxxx
Read table 3rd data
004H
TB3
R/W
xxxx
Read table 4th data
005H
DPL
R/W
xxxx
Data pointer low nibble data
006H
DPM
R/W
xxxx
Data pointer middle nibble data
007H
DPH
R/W
xxxx
Data pointer high nibble data
