Preliminary

TTP259

TonTouch

2015/05/25

Page 33 of 81

Ver: 1.1

P-4: 12-bit Timer/Counter/PWM for TCP2

One 12-bit timer/counter (TCP2) with 4 kind clock sources and preload

data buffer can implement as a timer or counter feature. The clock sources of

TCP2 are selected by TCP2S1~TCP2S0 of TCP2 control register (TCP2C).

TCP2OV is the timer or counter overflow signal and the rising edge will set the

relative INT flag.

TCP2C[203H]: TCP2 Timer/counter/PWM control register [R/W], default value [0000]

Bit3

Bit2

Bit1

Bit0

Bit Name

TCP2LD

TCP2S1

TCP2S0

TCP2EN

Read/Write

R/W

TCP2EN: TCP2 counting enable. (0: disable; 1: enable)

TCP2LD: TCP2 auto-reload enable. (0: disable; 1: enable)

TCP2S1~TCP2S0: TCP2 clock source selector.

TCP2S1

TCP2S0

Selected Clock source

OSCH

TBCK

TCP1OV

TCP2L[204H]: TCP2 low nibble data register [R/W], default value [0000]

Bit3

Bit2

Bit1

Bit0

Bit Name TCP2_3/TCP2D3 TCP2_2/TCP2D2 TCP2_1/TCP2D1 TCP2_0/TCP2D0

Read/Write

R/W

TCP2_3~TCP2_0: Reading TCP2 counter low nibble data.

TCP2D3~TCP2D0: Writing TCP2D low nibble of data buffer.

TCP2M[205H]:TCP2 middle nibble data register [R/W], default value [0000]

Bit3

Bit2

Bit1

Bit0

Bit Name TCP2_7/TCP2D7 TCP2_6/TCP2D6 TCP2_5/TCP2D5 TCP2_4/TCP2D4

Read/Write

R/W

TCP2_7~TCP2_4: Reading TCP2 counter middle nibble data.

TCP2D7~TCP2D4: Writing TCP2D middle nibble of data buffer.
