43 / 81 page  Preliminary TTP259 TonTouch TM 2015/05/25 Page 43 of 81 Ver: 1.1 INTC1[00CH]: Extended interrupt control register [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name STIE IICIE INT1IE INT0IE Read/Write R/W R/W R/W R/W INT0IE: enable INT0 external interrupt. (0: disable; 1: enable) INT1IE: enable INT1 external interrupt. (0: disable; 1: enable) IICIE: enable IIC interrupt. (0: disable; 1: enable) STIE: enable IIC start signal interrupt. (0: disable; 1: enable) INTF1[00DH]: Extended interrupt request flag register [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name STIF IICF INT1F INT0F Read/Write R/W R/W R/W R/W INT0F: INT0 external interrupt request flag. (0: inactive; 1: active) INT1F: INT1 external interrupt request flag. (0: inactive; 1: active) IICF: IIC interrupt request flag. (0: inactive; 1: active) STIF: IIC start signal interrupt request flag. (0: inactive; 1: active) IICCON0[221H]: IIC control register 0 [R/W], default value [---1] Register Bit3 Bit2 Bit1 Bit0 Bit Name - - - IICMOD Read/Write - - - R/W IICMOD: IIC Operation mode. (0: normal; 1: fast read) IICCON1[222H]: IIC control register 1 [R/W], default value [0000] Register Bit3 Bit2 Bit1 Bit0 Bit Name ADR2 ADR1 ADR0 IICEN Read/Write R/W R/W R/W R/W IICEN: IIC function enable. (0: disable; 1: enable) ADR2~ADR0: IIC slave address. |
|
