Preliminary
TTP259
TonTouch
TM
2015/05/25
Page 29 of 81
Ver: 1.1
TBC[20EH]: Time base control register [R/W], default value [1111]
Register
Bit3
Bit2
Bit1
Bit0
Bit Name
TB2S
TB1S2
TB1S1
TB1S0
Read/Write
R/W
R/W
R/W
R/W
TB1S2~TB1S0: Time base 1st overflow frequency selector.
TB2S: Time base 2nd overflow frequency selector.
Note: Every time writing the TBRB will clear the time base.
TB1S2 TB1S1 TB1S0
Time Base overflow
frequency (TB1OV)
TB1OV
0
0
0
TBCK/128
128HZ
0
0
1
TBCK/256
64HZ
0
1
0
TBCK/512
32HZ
0
1
1
TBCK/1024
16HZ
1
0
0
TBCK/2048
8HZ
1
0
1
TBCK/4096
4HZ
1
1
0
TBCK/8192
2HZ
1
1
1
TBCK/16384
1HZ
TB2S
Time Base overflow
frequency (TB2OV)
TB2OV
0
TBCK/512
32Hz
1
TBCK/1024
16Hz
Note: TB1OV select 128Hz can not be use for TCP1 clock source, the TCP1 will not
work. Please use other time base select option.
