Preliminary
TTP259
TonTouch
TM
2015/05/25
Page 27 of 81
Ver: 1.1
P-1-1: OSC Frequency Adjustment
ADJSTAT[230H]: Frequency Adjustment Status flag register [R], default value [--11]
Register
Bit3
Bit2
Bit1
Bit0
Bit Name
-
-
OSCHADJF
TBADJF
Read/Write
-
-
R
R
TBADJF: Time base adjustment status flag. (0: busy, 1: idle)
OSCHADJF: OSCH frequency adjustment status flag. (0: busy, 1: idle)
SPCON1 [21CH]: Special control register 1 [R/W], default value [0000]
Register
Bit3
Bit2
Bit1
Bit0
Bit Name
INTTS
FST2
FST1
FST0
Read/write
R/W
R/W
R/W
R/W
FST2~FST0: Frequency Shift Time selector.
FST2~FST0
Frequency Shift Time (us)
000
OFF
001
4
010
8
011
16
100
32
101
64
110
128
111
256
OSCHADJ [220H]: OSCH frequency adjustment register [R/W], default value [0001]
Register
Bit3
Bit2
Bit1
Bit0
Bit Name
ADJ3
ADJ2
ADJ1
ADJ0
Read/write
R/W
R/W
R/W
R/W
ADJ3~ADJ0: OSCH frequency adjustment data.
OSCHADJ set the frequency swing range, when the change time in register
FS2~FS0
FS
FS2~FS0
FS
0
OSCH/1
4
OSCH/16
1
OSCH/2
5
OSCH/32
2
OSCH/4
6
OSCH/64
3
OSCH/8
7
OSCH/128
