TTP259-ASFN Datasheet(PDF) 12 Page - Tontek Design Technology |
|
|
|||||||||||||||||||||||||||||
TTP259-ASFN Datasheet(HTML) 12 Page - Tontek Design Technology |
|
|
12 / 81 page  Preliminary TTP259 TonTouch TM 2015/05/25 Page 12 of 81 Ver: 1.1 § Peripheral registers: Address Symbol R/W Default Description 008H PS R/W -100 CPU power saving control register 009H PSP R/W 0--- Peripheral power saving control register 00AH INTC R/W 0000 Interrupt enable control register 00BH INTF R/W 0000 Interrupt request flag register 00CH INTC1 R/W 0000 Extended interrupt enable control register 00DH INTF1 R/W 0000 Extended interrupt request flag register 00EH PWMC R/W -000 PWM control register 00FH PWM0L R/W xxxx PWM0 duty low nibble data register 010H PWM0M R/W xxxx PWM0 duty middle nibble data register 011H PWM0H R/W xxxx PWM0 duty high nibble data register 012H PAC R/W -111 IO port A control register 013H PA R/W -111 IO port A output data register 014H PBC R/W 1111 IO port B control register 015H PB R/W 1111 IO port B output data register 016H PCC R/W 1111 IO port C control register 017H PC R/W 1111 IO port C output data register 018H PDC R/W 1111 IO port D control register 019H PD R/W 1111 IO port D output data register 01AH PEC R/W 1111 IO port E control register 01BH PE R/W 1111 IO port E output data register 01CH PFC R/W 1111 IO port F control register 01DH PF R/W 1111 IO port F output data register 01EH TPINTC R/W 00-- Touch pad interrupt enable control register 01FH TPINTF R/W 00-- Touch pad interrupt request flag register |
|
