CC1100

SWRS038D

Page 48 of 92

Frequency Programming

The frequency programming in

CC1100 is

designed

minimize

the

programming

needed in a channel-oriented system.

To set up a system with channel numbers, the

desired channel spacing is programmed with

the

MDMCFG0.CHANSPC_M

and

MDMCFG1.CHANSPC_E

registers. The channel

spacing registers are mantissa and exponent

respectively.

The base or start frequency is set by the 24 bit

frequency word located in the FREQ2, FREQ1,

and FREQ0 registers. This word will typically

be set to the centre of the lowest channel

frequency that is to be used.

The desired channel number is programmed

with the 8-bit channel number register,

CHANNR.CHAN

, which is multiplied by the

channel offset. The resultant carrier frequency

is given by:

()

256

−

⋅

CHANSPC

XOSC

carrier

CHANSPC

CHAN

FREQ

With a 26 MHz crystal the maximum channel

spacing is 405 kHz. To get e.g. 1 MHz channel

spacing one solution is to use 333 kHz

channel spacing and select each third channel

in CHANNR.CHAN.

The preferred IF frequency is programmed

with the FSCTRL1.FREQ_IF register. The IF

frequency is given by:

FREQ

XOSC

⋅

Note that the SmartRF

® Studio software [7]

automatically

calculates

the

optimum

FSCTRL1.FREQ_IF

channel spacing and channel filter bandwidth.

If any frequency programming register is

altered when the frequency synthesizer is

running,

the

synthesizer

may

give

undesired response. Hence, the frequency

programming should only be updated when

the radio is in the IDLE state.

VCO

The VCO is completely integrated on-chip.

22.1 VCO and PLL Self-Calibration

The VCO characteristics will vary with

temperature and supply voltage changes, as

well as the desired operating frequency. In

order to ensure reliable operation,

CC1100

includes frequency synthesizer self-calibration

circuitry. This calibration should be done

regularly, and must be performed after turning

on power and before using a new frequency

(or channel). The number of XOSC cycles for

completing the PLL calibration is given in

Table 28 on page 45.

The calibration can be initiated automatically

manually.

The

synthesizer

can

automatically

calibrated

each

time

the

synthesizer is turned on, or each time the

synthesizer is turned off automatically. This is

configured with the

MCSM0.FS_AUTOCAL

setting.

manual

mode,

the

calibration

initiated

when

the

SCAL

command strobe is activated in the IDLE

mode.

Note that the calibration values are maintained

in SLEEP mode, so the calibration is still valid

after waking up from SLEEP mode (unless

supply voltage or temperature has changed

significantly).

To check that the PLL is in lock the user can

program register IOCFGx.GDOx_CFG to 0x0A

and use the lock detector output available on

the GDOx pin as an interrupt for the MCU (x =

0,1, or 2). A positive transition on the GDOx

pin means that the PLL is in lock. As an

alternative the user can read register FSCAL1.

The PLL is in lock if the register content is

different from 0x3F. Refer also to the

CC1100

Errata Notes [1]. For more robust operation the

source code could include a check so that the

PLL is re-calibrated until PLL lock is achieved

if the PLL does not lock the first time.
