CC1100

SWRS038D

Page 12 of 92

Parameter

Min

Typ

Max

Unit

Condition/Note

Blocking

Blocking at ±2 MHz offset,

1.2 kBaud, 868 MHz

-53

dBm

Desired channel 3dB above the sensitivity limit. Compliant

with ETSI EN 300 220 class 2 receiver requirement.

Blocking at ±2 MHz offset,

500 kBaud, 868 MHz

-51

dBm

Desired channel 3dB above the sensitivity limit. Compliant

with ETSI EN 300 220 class 2 receiver requirement.

Blocking at ±10 MHz offset,

1.2 kBaud, 868 MHz

-43

dBm

Desired channel 3dB above the sensitivity limit. Compliant

with ETSI EN 300 220 class 2 receiver requirement.

Blocking at ±10 MHz offset,

500 kBaud, 868 MHz

-43

dBm

Desired channel 3dB above the sensitivity limit. Compliant

with ETSI EN 300 220 class 2 receiver requirement.

General

Spurious emissions

-68

-66

–57

–47

dBm

25 MHz – 1 GHz

(Maximum figure is the ETSI EN 300 220 limit)

Above 1 GHz

(Maximum figure is the ETSI EN 300 220 limit)

RX latency

bit

Serial operation. Time from start of reception until data is

available on the receiver data output pin is equal to 9 bit.

Table 5: RF Receive Section
