0x1B: AGCCTRL2 – AGC Control

Bit

Field Name

Reset

R/W

Description

7:6

MAX_DVGA_GAIN[1:0]

0 (00)

R/W

Reduces the maximum allowable DVGA gain.

Setting

Allowable DVGA settings

0 (00)

All gain settings can be used

1 (01)

The highest gain setting can not be used

2 (10)

The 2 highest gain settings can not be used

3 (11)

The 3 highest gain settings can not be used

5:3

MAX_LNA_GAIN[2:0]

0 (000)

R/W

Sets the maximum allowable LNA + LNA 2 gain relative to the

maximum possible gain.

Setting

Maximum allowable LNA + LNA 2 gain

0 (000)

Maximum possible LNA + LNA 2 gain

1 (001)

Approx. 2.6 dB below maximum possible gain

2 (010)

Approx. 6.1 dB below maximum possible gain

3 (011)

Approx. 7.4 dB below maximum possible gain

4 (100)

Approx. 9.2 dB below maximum possible gain

5 (101)

Approx. 11.5 dB below maximum possible gain

6 (110)

Approx. 14.6 dB below maximum possible gain

7 (111)

Approx. 17.1 dB below maximum possible gain

2:0

MAGN_TARGET[2:0]

3 (011)

R/W

These bits set the target value for the averaged amplitude from the

digital channel filter (1 LSB = 0 dB).

Setting

Target amplitude from channel filter

0 (000)

24 dB

1 (001)

27 dB

2 (010)

30 dB

3 (011)

33 dB

4 (100)

36 dB

5 (101)

38 dB

6 (110)

40 dB

7 (111)

42 dB
