80 / 100 page  CC1100 SWRS038D Page 80 of 92 0x1D: AGCCTRL0 – AGC Control Bit Field Name Reset R/W Description 7:6 HYST_LEVEL[1:0] 2 (10) R/W Sets the level of hysteresis on the magnitude deviation (internal AGC signal that determine gain changes). Setting Description 0 (00) No hysteresis, small symmetric dead zone, high gain 1 (01) Low hysteresis, small asymmetric dead zone, medium gain 2 (10) Medium hysteresis, medium asymmetric dead zone, medium gain 3 (11) Large hysteresis, large asymmetric dead zone, low gain 5:4 WAIT_TIME[1:0] 1 (01) R/W Sets the number of channel filter samples from a gain adjustment has been made until the AGC algorithm starts accumulating new samples. Setting Channel filter samples 0 (00) 8 1 (01) 16 2 (10) 24 3 (11) 32 3:2 AGC_FREEZE[1:0] 0 (00) R/W Control when the AGC gain should be frozen. Setting Function 0 (00) Normal operation. Always adjust gain when required. 1 (01) The gain setting is frozen when a sync word has been found. 2 (10) Manually freeze the analogue gain setting and continue to adjust the digital gain. 3 (11) Manually freezes both the analogue and the digital gain setting. Used for manually overriding the gain. 1:0 FILTER_LENGTH[1:0] 1 (01) R/W Sets the averaging length for the amplitude from the channel filter. Sets the OOK/ASK decision boundary for OOK/ASK reception. Setting Channel filter samples OOK decision 0 (00) 8 4 dB 1 (01) 16 8 dB 2 (10) 32 12 dB 3 (11) 64 16 dB 0x1E: WOREVT1 – High Byte Event0 Timeout Bit Field Name Reset R/W Description 7:0 EVENT0[15:8] 135 (0x87) R/W High byte of EVENT0 timeout register RES WOR XOSC Event EVENT f t _ 5 0 2 0 750 ⋅ ⋅ ⋅ = |
|
