Asynchronous and Synchronous Serial Operation

Several features and modes of operation have

been included in the

CC1100 to provide

backward compatibility with previous Chipcon

products and other existing RF communication

systems. For new systems, it is recommended

to use the built-in packet handling features, as

they can give more robust communication,

significantly offload the microcontroller, and

simplify software development.

31.1 Asynchronous Operation

For backward compatibility with systems

already using the asynchronous data transfer

from other Chipcon products, asynchronous

transfer is also included in

CC1100. When

asynchronous transfer is enabled, several of

the support mechanisms for the MCU that are

included in

CC1100 will be disabled, such as

packet handling hardware, buffering in the

FIFO, and so on. The asynchronous transfer

mode does not allow the use of the data

whitener, interleaver, and FEC, and it is not

possible to use Manchester encoding.

Note

that

MSK

not

supported

for

asynchronous transfer.

Setting

PKTCTRL0.PKT_FORMAT

enables asynchronous serial mode.

In TX, the GDO0 pin is used for data input (TX

data). Data output can be on GDO0, GDO1, or

GDO2. This is set by the IOCFG0.GDO0_CFG,

IOCFG1.GDO1_CFG

and IOCFG2.GDO2_CFG

fields.

The

CC1100 modulator samples the level of the

asynchronous input 8 times faster than the

programmed data rate. The timing requirement

for the asynchronous stream is that the error in

the bit period must be less than one eighth of

the programmed data rate.

31.2 Synchronous Serial Operation

Setting

PKTCTRL0.PKT_FORMAT

enables synchronous serial mode. In the

synchronous serial mode, data is transferred

on a two wire serial interface. The

CC1100

provides a clock that is used to set up new

data on the data input line or sample data on

the data output line. Data input (TX data) is the

GDO0 pin. This pin will automatically be

configured as an input when TX is active. The

data output pin can be any of the GDO pins;

this is set by the IOCFG0.GDO0_CFG,

IOCFG1.GDO1_CFG

, and IOCFG2.GDO2_CFG

fields.

Preamble and sync word insertion/detection

may or may not be active, dependent on the

sync mode set by the MDMCFG2.SYNC_MODE.

If preamble and sync word is disabled, all

other packet handler features and FEC should

also be disabled. The MCU must then handle

preamble and sync word insertion and

detection in software. If preamble and sync

word insertion/detection is left on, all packet

handling features and FEC can be used. One

exception is that the address filtering feature is

unavailable in synchronous serial mode.

When using the packet handling features in

synchronous serial mode, the

CC1100 will insert

and detect the preamble and sync word and

the MCU will only provide/get the data

payload.

This

equivalent

the

recommended FIFO operation mode.

System Considerations and Guidelines

32.1 SRD Regulations

International regulations and national laws

regulate the use of radio receivers and

transmitters. Short Range Devices (SRDs) for

license free operation below 1 GHz are usually

operated in the 433 MHz, 868 MHz or 915

MHz

frequency

bands.

The

CC1100 is

specifically designed for such use with its 300 -

348 MHz, 400 - 464 MHz, and 800 - 928 MHz

operating

ranges.

The

most

important

regulations when using the

CC1100 in the 433

MHz, 868 MHz, or 915 MHz frequency bands

are EN 300 220 (Europe) and FCC CFR47

part 15 (USA). A summary of the most

important aspects of these regulations can be

found in Application Note AN001 [2].

Please note that compliance with regulations is

dependent on complete system performance.

It is the customer’s responsibility to ensure that

the system complies with regulations.
