CC1100

SWRS038D

Page 74 of 92

0x17: MCSM1– Main Radio Control State Machine Configuration

Bit

Field Name

Reset

R/W

Description

7:6

Reserved

5:4

CCA_MODE[1:0]

3 (11)

R/W

Selects CCA_MODE; Reflected in CCA signal

Setting

Clear channel indication

0 (00)

Always

1 (01)

If RSSI below threshold

2 (10)

Unless currently receiving a packet

3 (11)

If RSSI below threshold unless currently

receiving a packet

3:2

RXOFF_MODE[1:0]

0 (00)

R/W

Select what should happen when a packet has been received

Setting

Next state after finishing packet reception

0 (00)

IDLE

1 (01)

FSTXON

2 (10)

3 (11)

Stay in RX

It is not possible to set RXOFF_MODE to be TX or FSTXON and at the same

time use CCA.

1:0

TXOFF_MODE[1:0]

0 (00)

R/W

Select what should happen when a packet has been sent (TX)

Setting

Next state after finishing packet transmission

0 (00)

IDLE

1 (01)

FSTXON

2 (10)

Stay in TX (start sending preamble)

3 (11)
