22 / 171 page  Flash program memory ST7DALIF2 22/171 6.6 Related documentation For details on Flash programming and ICC protocol, refer to the ST7 Flash Programming Reference Manual and to the ST7 ICC Protocol Reference Manual. 6.7 Register description 6.7.1 Flash control/status register (FCSR) This register is reserved for programming using ICP, IAP or other programming methods. It controls the XFlash programming and erasing operations. When an EPB or another programming tool is used (in socket or ICP mode), the RASS keys are sent automatically. 1st RASS Key: 0101 0110 (56h) 2nd RASS Key: 1010 1110 (AEh) FCSR Reset value: 0000 0000 (00h) 76 543 21 0 00 000 OPT LAT PGM R/W R/W R/W R/W R/W R/W R/W R/W Table 4. Flash control/status register address and reset value Address (Hex) Register label 7 6 5 4 3 2 1 0 002Fh FCSR reset value 0 0 0 0 0 0 0 0 |
|
