ST7DALIF2

Supply, reset and clock management

33/171

Note:

Section 20: Electrical characteristics on page 127 for more information on the frequency

and accuracy of the RC oscillator.

To improve clock stability and frequency accuracy, it is recommended to place a decoupling

capacitor, typically 100nF, between the VDD and VSS pins as close as possible to the ST7

device.

These two bytes are systematically programmed by ST, including on FASTROM devices.

Consequently, customers intending to use FASTROM service must not use these two bytes.

RCCR0 and RCCR1 calibration values will be erased if the readout protection bit is reset

after it has been set. See Readout protection on page 21

Caution:

If the voltage or temperature conditions change in the application, the frequency may need

to be recalibrated.

Refer to application note AN1324 for information on how to calibrate the RC frequency using

an external reference signal.

9.3

Phase locked loop

The PLL can be used to multiply a 1 MHz frequency from the RC oscillator or the external

clock by 4 or 8 to obtain fOSC2 of 4 or 8 MHz. The PLL is enabled and the multiplication

factor of 4 or 8 is selected by 2 option bits.

●

The x4 PLL is intended for operation with VDD in the 2.4 V to 3.3 V range

●

The x8 PLL is intended for operation with VDD in the 3.3 V to 5.5 V range

Refer to Section 22.1 on page 161 for the option byte description.

If the PLL is disabled and the RC oscillator is enabled, then fOSC2 = 1 MHz.

If both the RC oscillator and the PLL are disabled, fOSC is driven by the external clock.

Table 9.

RC control registers

RCCR

Conditions

ST7DALI address

RCCR0

VDD=5V

TA=25°C

fRC=1MHz

1000h

and FFDEh

RCCR1

VDD=3V

TA=25°C

fRC=700KHz

1001h

and FFDFh
