27 / 171 page  ST7DALIF2 Data EEPROM 27/171 7.7 Register description 7.8 EEPROM control/status register (EECSR) Read/Write Reset Value: 0000 0000 (00h) Bits 7:2 = Reserved, forced by hardware to 0. Bit 1 = E2LAT Latch Access Transfer This bit is set by software. It is cleared by hardware at the end of the programming cycle. It can only be cleared by software if the E2PGM bit is cleared. 0: Read mode 1: Write mode Bit 0 = E2PGM Programming control and status This bit is set by software to begin the programming cycle. At the end of the programming cycle, this bit is cleared by hardware. 0: Programming finished or not yet started 1: Programming cycle is in progress Note: If the E2PGM bit is cleared during the programming cycle, the memory data is not guaranteed 7 0 000000 E2LAT E2PGM Table 5. Data EEPROM register map and reset values Address (Hex.) Register label 7654 3210 0030h EECSR Reset Value 0000 00 E2LAT 0 E2PGM 0 |
|
