44 / 171 page ![]() Supply, reset and clock management ST7DALIF2 44/171 9.7.4 Register description System integrity (SI) control/status register (SICSR) Read/Write Reset Value: 0000 0xx0 (0xh) Bit 7:5 = Reserved, must be kept cleared. Bit 4 = WDGRF Watchdog reset flag This bit indicates that the last Reset was generated by the Watchdog peripheral. It is set by hardware (watchdog reset) and cleared by software (writing zero) or an LVD Reset (to ensure a stable cleared state of the WDGRF flag when CPU starts). Combined with the LVDRF flag information, the flag description is given by the following table. Bit 3 = LOCKED PLL Locked Flag This bit is set and cleared by hardware. It is set automatically when the PLL reaches its operating frequency. 0: PLL not locked 1: PLL locked Bit 2 = LVDRF LVD reset flag This bit indicates that the last Reset was generated by the LVD block. It is set by hardware (LVD reset) and cleared by software (by reading). When the LVD is disabled by OPTION BYTE, the LVDRF bit value is undefined. Bit 1 = AVDF Voltage Detector flag This read-only bit is set and cleared by hardware. If the AVDIE bit is set, an interrupt request is generated when the AVDF bit is set. Refer to Figure 18 and to Monitoring the VDD main supply on page 42 for additional details. 0: VDD over AVD threshold 1: VDD under AVD threshold Bit 0 = AVDIE Voltage Detector interrupt enable This bit is set and cleared by software. It enables an interrupt to be generated when the AVDF flag is set. The pending interrupt information is automatically cleared when software enters the AVD interrupt routine. 0: AVD interrupt disabled 1: AVD interrupt enabled Note: The LVDRF flag is not cleared when another RESET type occurs (external or watchdog), the LVDRF flag remains set to keep trace of the original failure. In this case, a watchdog reset can be detected by software while an external reset can not. 7 0 0 0 0 WDGRF LOCKED LVDRF AVDF AVDIE Table 14. Reset flags RESET sources LVDRF WDGRF External RESET pin 0 0 Watchdog 0 1 LVD 1 X |
|
